XHX-Cummins
Hensing Brand or Customization
CUMMINS
SerieGrupos electrógenos diesel
Cobertura de energía de 27.5kva ~ 1475kva
Motor: MARCA CUMMINS
Velocidad: 1500/1800 rpm
Alternador: Stamford/Leroisómero/Maratón/Mecc Alt / Tipo Stamford sin escobillas
IP y clase de aislamiento: IP22-23 y F / H
Frecuencia: 50/60 HZ
Controlador: Deepsea/Smartgen / Datakom/Marca ComAp / XHXOwn
Nivel de sonido silencioso del grupo electrógeno: 75-83db (a 7 m de distancia)
Supper Silent Gen-set Nivel de sonido: 63-75db (a 7 m de distancia)
Rendimiento del grupo electrógeno | Rendimiento del grupo electrógeno | Dimensión | |||||||
Modelo | POTENCIA DE SALIDA | Fra. | MOTOR | Poder | Consumo de combustible | Cilindro | Tipo abierto / peso | tipo insonorizado/peso | |
SALIDA PRIME (KW / KWy | S1 Y POR POTENCIA (KW / KW) | ||||||||
HZ | MODEL | KW | L7H | No. | mm / kg | mm / kg | |||
XHX-C22 | 22127.5 | 24/30 | 50 | 4B3.9-G1 | 24 | 6.3 | 4 | 1800x850x1260 / 620 | 2250x950x1300 / 890 |
XHX-C22 | 22 / 27,5 | 24/30 | 50 | 4B3.9-G2 | 24 | 6.3 | 4 | 1800x850x1260 / 630 | 2250x950x1300 / 900 |
XHX-C32 | 32/40 | 35/44 | 50 | 4BT3.9-G1 | 36 | 8.7 | 4 | 1800x850x1260 / 650 | 2250x950x1300 / 950 |
XHX-C40 | 32/40 | 35/44 | 50 | 4BT3.9-G2 | 36 | 8.7 | 4 | 1800x850x1260 / 660 | 2250x950x1300 / 960 |
XHX-C45 | 45/56 | 50/62 | 50 | 4BTA3.9-G2 | 58 | 13.8 | 4 | 1850x850x1260 / 800 | 2250x950x1300 / 1100 |
XHX-C52 | 52/65 | 56/70 | 50 | 4BTA3.9-G2 | 58 | 13.8 | 4 | 1850x850x1260 / 84。 | 2300x950x1300 / 1120 |
5 l \ Z | 64/80 | 72/90 | 50 | 4BTA3.9-G11 | 70 | 13.8 | 4 | 1950x850x1260 / 1000 | 2350 x 950 x 1350/1150 |
XHX-C75 | 75/94 | 82/103 | 50 | 6BT5.9-G1 | 86 | 16 | 6 | 2250x860x1300 / 1080 | 2800x1050x1380 / 1430 |
XHX-C75 | 75/94 | 82/103 | 50 | 6BT5.9-G2 | 96 | 16 | 6 | 2250x860x1300 / 1100 | 2800x1050x1380 / 1440 |
XHX-C84 | 84/105 | 92/115 | 50 | 6BT5.9-G2 | 96 | 17.9 | 6 | 2250x860x1300 / 1110 | 2800x1050x1380 / 1420 |
XHX-C90 | 90/110 | 100/125 | 50 | 6B1A5.9-G2 | 106 | 19.4 | 6 | 2300x860x1350 / 1200 | 2800x1050x1480 / 1550 |
XHX-C100 | 100/125 | 110 / 137,5 | 50 | 6BTAA5.9-G2 | 120 | 21.6 | 6 | 2400x860x1500 / 1300 | 2800x1050x15801620 |
XHX-C120 | 120/150 | 132/165 | 50 | 6BTAA5.9-G12 | 140 | 25.9 | 6 | 2400x860x1500 / 1320 | 2800x1050x1580 / 1650 |
XHX-C145 | 145/180 | 160/200 | 50 | 6C7A8.3-G1 | 163 | 31.3 | 6 | 2600x980x1550 / 1480 | 3000x1050x1680 / 1980 |
XHX-C145 | 145/180 | 160/200 | 50 | 6C7A8.3-G2 | 163 | 31.3 | 6 | 2600 x 980 x 1550/1650 | 3000x1050x1680 / 2000 |
XHX-C160 | 160/200 | 172/215 | 50 | 6CTAA8.3-G2 | 183 | 34.5 | 6 | 2600x980x1550 / 1780 | 3000x1050x1680 / 2250 |
XHX-C200 | 200/250 | 220/275 | 50 | 6LTAA8.9-G2 | 220 | 43.2 | 6 | 2650x100x1600 / 1800 | 3200x1300x1700 / 2280 |
XHX-C210 | 210/260 | 230/290 | 50 | 6LTAA8.9-G3 | 230 | 45.6 | 6 | 2650x100x1600 / 1810 | 3200x1300x1700 / 2300 |
XHX-C310 | 310/388 | 340/425 | 50 | 6ZTAA13-G3 | 340 | 66.9 | 6 | 3000x1150x1780 / 3800 | 3800x1550x2100 / 5260 |
XHX-C350 | 350/438 | 380/475 | 50 | 6Z7AA13 ・ G2 | 390 | 75.6 | 6 | 3350x1150x1780 / 4200 | 4200x1550x2100 / 5670 |
XHX-C350 | 350/438 | 380/475 | 50 | 6Z1AA13-G4 | 400 | 75.6 | 6 | 3350x1150x1780 / 4230 | 4200x1550x2100 / 5700 |
XHX-C350 | 350/438 | 375/468 | 50 | QZS13-G2 | 400 | 75.6 | 6 | 3350x1150x1780 / 4230 | 4200x1550x2100 / 5700 |
XHX-C380 | 380/475 | 400/500 | 50 | QSZ13-G3 | 450 | 82 | 6 | 3400x1150x1780 / 4250 | 4200x1550x2100 / 5720 |
XHX-C360 | 360/450 | 400/500 | 50 | QSZ13-G5 | 411 | 77.7 | 6 | 3400x1150x1780 / 4270 | 4200x1550x2100 / 5750 |
XHX-C200 | 200/250 | 220/275 | 50 | MTA11-G2A | 234 | 36 | 6 | 2950x1160x1900 / 2430 | 3700 x 1450 x 2000/3100 |
XHX-C200 | 200/250 | 220/275 | 50 | M7A11-G2 | 224 | 36 | 6 | 2950x1160x1900 / 2430 | 3700 x 1450 x 2000/3100 |
XHX-C200 | 200/250 | 220/275 | 50 | NT855-GA | 231 | 36 | 6 | 2950x1160x1900 / 2430 | 3700 x 1450 x 2000/3100 |
XHX-C200 | 200/250 | 220/275 | 50 | NTA855-G1 | 240 | 36 | 6 | 2950x1160x1900 / 2430 | 3700 x 1450 x 2000/3100 |
XHX-C250 | 250/313 | 280/350 | 50 | MTAA11-G3 | 282 | 57 | 6 | 3100x1160x1780 / 3065 | 3800 x 1450 x 2000/3800 |
XHX-C220 | 220/275 | 250 / 312,5 | 50 | NTA855-G1A | 264 | 40 | 6 | 3100x1160x1780 / 3065 | 3800 x 1450 x 2000/3800 |
XHX-C250 | 250/313 | 280/350 | 50 | N7A855-G1B | 284 | 67.4 | 6 | 3100x1160x1780 / 3065 | 3800 x 1450 x 2000/3800 |
XHX-C280 | 280/350 | 310 / 387,5 | 50 | N7A855-G2A | 312 | 66.7 | 6 | 3100x1160x1780 / 3065 | 3800 x 1450 x 2000/3800 |
XHX-C300 | 300/375 | 330 / 412,5 | 50 | NW855 ・ G7 | 343 | 78 | 6 | 3100x1160x1780 / 3065 | 3800 x 1450 x 2000/3800 |
XHX-C320 | 320/400 | 350/440 | 50 | N1AA855-G7A | 360 | 90.9 | 6 | 3100x1160x1780 / 3065 | 4000 x 1450 x 2000/3900 |
XHX-C360 | 360/450 | 400/500 | 50 | KTA19-G3 | 403 | 92.4 | 6 | 3400x1400x2150 / 3700 | 4250x1800x2300 / 4800 |
XHX-C400 | 400/500 | 440/550 | 50 | KTA19-G3A | 448 | 101.9 | 6 | 3400x1400x2150 / 4100 | 4250x1800x2200 / 5250 |
XHX-C400 | 400/500 | 440/550 | 50 | KTA19-G4 | 448 | 101.9 | 6 | 3400x1400x2150 / 4100 | 4250x1800x2200 / 5250 |
XHX-C420 | 420/525 | 505/631 | 50 | K7AA19-G5 | 470 | 106.9 | 6 | 3500x1550x2300 / 4500 | 4500x1800x2400 / 5540 |
XHX-C470 | 470/587 | 520/650 | 50 | KTA19-G8 | 520 | 119.3 | 6 | 3500x1550x2300 / 4580 | 4500x1800x2400 / 5650 |
XHX-C500 | 500/625 | 550/687 | 50 | K1AA19-G6A | 558 | 140.2 | 6 | 3500x1550x2300 / 4580 | 4500x1800x2200 / 5650 |
XHX-C580 | 580/725 | 640/800 | 50 | KT38-GA | 647 | 150.9 | 12 | 4300X1800X2450 / 7500 | 5500X2100X2500 / 9500 |
XHX-C600 | 600/750 | 660/825 | 50 | KTA38-G2 | 664 | 156.2 | 12 | 4300X1800X2450 / 7500 | 5500X2100X2500 / 9500 |
XHX-C640 | 640/800 | 700/875 | 50 | KTA38-G2B | 711 | 158.8 | 12 | 4350x1800x2450 / 7500 | 5700x2100x2500 / 9600 |
XHX-C720 | 720/910 | 800/1000 | 50 | K7A38-G2A | 813 | 179.5 | 12 | 4350x1800x2450 / 7500 | 5700x2100x2500 / 9600 |
XHX-C800 | 800/1000 | 880/1100 | 50 | KTA38-G5 | 880 | 200 | 12 | 4500x1800x2500 / 7600 | 6058x2438x2591 / 10000 |
XHX-C900 | 900/1125 | 1000/1250 | 50 | KTA38-G9 | 980 | 220 | 12 | 4700x2000x2500 / 7800 | 6058x2438x2591 / 10500 |
XHX-C1000 | 1000/1250 | 1100/1375 | 50 | KTA50-G3 | 1097 | 244.3 | 16 | 4500x2000x2580 / 10120 | 12192 * 2438x2896 / 14120 |
XHX-C1100 | 1100/1375 | 1320/1650 | 50 | KTA50-G8 | 1200 | 268 | 16 | 4500x2000x2580 / 10600 | 12192x2438x2896 / 14600 |
XHX-C1180 | 1180/1475 | 1320/1650 | 50 | K7A50-GS8 | 1287 | 287 | 16 | 4500x2000x2580 / 10600 | 12192x2438x2896 / 14600 |
